The sludge conveying screw pump, usually referred to as a single-screw pump (Monorotor pump), is a type of volumetric positive displacement pump that uses a single helical rotor (screw) to rotate in a double-helical elastic stator cavity in a planetary manner, forming continuous and sealed chambers to transport the medium. It is a key equipment for transporting high-viscosity, high-solid-content, and non-flowable media in municipal and industrial sludge treatment fields.
Product Parameters
| Head | 120 meters |
| Power | 22kw |
| Rated flow | 70 |
Product structure diagram
Product features
Strong self-priming and conveying capabilities: Structurally, it has a strong self-priming ability (up to 8.5 meters of water column), which enables smooth and continuous transportation of sludge with extremely poor fluidity, high viscosity, or even semi-dry state, and the flow is stable without pulsation.
Outstanding media adaptability:
It can transport sludge with a solid content of up to 40%-70% after dewatering.
It can handle high-viscosity media (up to millions of cPs).
It has good passage for fine particles, fibers (such as hair, fabric), and is not prone to clogging.
Simple structure, easy maintenance: The core components are only the rotor and stator, without valves, and the structure is compact. Replacing wear parts (mainly the stator) is relatively simple.
Variable conveying, stable pressure: Flow rate is proportional to rotational speed. By variable frequency speed regulation, the conveying volume can be easily adjusted. The pressure at the outlet is established stably, suitable for working conditions requiring certain conveying pressure (such as feed to a filter press).
Application scenario
It is widely used in environmental protection and industrial processes that require the transportation of viscous and solid-containing sludge:
Municipal sewage treatment plants:
Transport the primary sedimentation sludge and residual activated sludge to the concentration tank.
Transport the concentrated sludge to the digestion tank or dewatering workshop.
As a stable feed pump for belt press filters, plate and frame press filters, and centrifugal dewatering machines.
Transport the dewatered sludge cake (a high-pressure model is required).
Industrial wastewater treatment: Transport various industrial sludges generated from industries such as papermaking, dyeing, leather, and chemical.
Other environmental protection fields:
River and pond dredging, transporting high-sand-content sludge.
Transporting organic slurry in food waste treatment.
Transporting oily sludge.
